Description
| Dimensions (mm) | 700 x 135 x 73 |
| Weight | 5.9 kg |
| Frequency Range | 5.15 – 5.85 GHz |
| Gain | 18.6 – 19.1 dBi |
| HPOL Beamwidth | 123? (6 dB) |
| VPOL Beamwidth | 123? (6 dB) |
| Electrical Beamwidth | 4? |
| Electrical Downtilt | 2? |
| Max. VSWR | 1.5:1 |
| Wind Survivability | 125 mph |
| Wind Loading | 20 lbf @ 100 mph |
| Polarization | Dual-Linear |
| Cross-pol Isolation | 28 dB Min. |
| ETSI Specification | EN 302 326 DN2 |
| Mounting | Universal Pole Mount, RocketM Bracket, and Weatherproof RF Jumpers Included |
